helix trommel
4 ton per hour trommel
Price: $5,000.00


Free local pick up
or
freight shipping extra $$

New reverse helix trommels
small scale commercial
up to 4 yards per hour
Mounted on 2x3 channel skids


1.5 Hp 110volt/220 volt or 6.5 gas
18" x 60" reverse helix concentrator tube
14" x 84" trommel barrel 1/4" hole
24" solid 48" 1/4" punch plate
48" x 24" hopper
10" input opening
1-1/4" water manifold
1-1/2" water inlet

You need Flash Player in order to view this.
Trommel test, hardrock tailings and gold
A trip to a Mariposa claim to help my friend ,Dale (owner of California Sluicebox Co) test his prototype new trommel.





 DO YOU NEED YOUR EQUIPMENT NOW?
SHORT ON MONEY? LET US HELP!
DURING CHECK OUT SELECT PAY LATER
  ROTARY CLASSIFIERS

You need Flash Player in order to view this.
trom field test


























12" GAS POWERED  HD TROMMEL
6.5 HP GAS ENGINE


BELT DRIVE

Freight runs 200.00-300.00


$ 1,650.00
12" ROTARY CLASSIFIER
6.5 HP belt drive 2 week lead time
Price: $1,650.00
 DO YOU NEED YOUR EQUIPMENT NOW?
SHORT ON MONEY? LET US HELP!
DURING CHECK OUT SELECT PAY LATER











The Green Giant

12" ROTARY CLASSIFIER with side discharge. Fine gold recovery sluice box makes this unit a gold getting machine. 2 yds. per hour




This big boy measures 75" long 46" tall
wheels 42" outside to outside.
Hopper 21" x 21" with three side spray bar
Machine frame 17.5" wide
machine barrel 49" long x 12" diameter
required water supply is 30 gpm



























































































































































































































































































1" sch 40 PVC spray bar system standard
1" steel spray bar system upgrade 150.00 (shown)

























 side discharge sluice box design
easy and fast change from right to left side helps to get the slop away from the work area.

engine is a 7 Hp Honda clone from HF tools
Quite and easy to manage and maintain v-belt system

long life trommel wheels easy to maintain and change out.

1/4" classification screen


Full Gimbel on sluice box support allows for easy leveling of the sluice box side to side when the trommel barrel angle is adjusted


9-1/4" wide sluice box, drop riffle design retains the micro fine gold.

























Gold recovered from demo run at shop from 5 gallon bucket of concentrates











































Clay scrubber full of water after demo run
















































































 Freight is paid by the buyer.
email us for a quote...
FREIGHT CLASS 92.5 ( rotary CLASSIFIER/JIG SEPARATOR )
NMFC 125320

We use Freight center .com

Freight items are based on the NMFC number and freight class
this is NOT like USPS or UPS
you can ship the same item with the same size and weight
but with a different (class) NMFC number and end up paying much more
for one of the items!

Tell your freight provider to lock in the NMFC class or they can change it at any time
and charge you more money some times double!

Do not use FREIGHT QUOTE dot com they are natorious for doing this!!!
